Description
LLZ034T4A
COMP SCROLL OPTYMA LLZ034T4LQ
Price (INC VAT)
ZARÂ 44,500.29
Product number:
1611534512
OEM Reference:
121L9543
| Product Group : | Scroll |
|---|
General
| Product Group : | Scroll |
|---|
Capacity
| Capacity Control : | Fixed speed |
|---|
Compressor
| Power Supply Compressor : | 380-415/3/50 460/3/60 V/Ph/Hz |
|---|---|
| Swept Volume : | 168.70 cm³ |
| Technique : | Scroll |
Connections
| Connection Type : | Rotolock |
|---|---|
| Discharge Connection Height : | 538 mm |
| Discharge Line Connection Size : | 1 1/4 in |
| Rotolock Discharge Line Connection : | 1 1/4 in |
| Rotolock Suction Connection : | 1 3/4 in |
| Suction Connection Height : | 374 mm |
| Suction Line Connection Size : | 1 3/4 in |
Electrical
| Frequency : | 50/60 Hz |
|---|---|
| IP Class : | IP22 |
| LRA : | 150 A |
| MCC : | 26 A |
| Phase : | 3 |
| RLA : | 16.7 A |
| Voltage : | 380/415/460 V |
General Information
| Colour : | Blue |
|---|---|
| Model Number : | LLZ034T4LQ9A |
| Type : | LLZ |
Logistical Information
| Commodity Code : | 84143081 |
|---|---|
| Country Of Origin : | CHN |
Measurements
| Diameter : | 184 mm |
|---|---|
| Height : | 565 mm |
| Length : | 232 mm |
| Net Weight : | 51 kg |
| Weight : | 51.00 kg |
| Width : | 232 mm |
Oil
| Oil Charge : | 2.51 L |
|---|---|
| Oil Equalization : | None |
| Oil Type : | POE |
Pressure
| Higher Active Pressure : | 28.5 Bar |
|---|---|
| Lower Active Pressure : | 25.4 Bar |
Refrigerant
| Max Refrigerant Charge : | 7.26 kg |
|---|---|
| Refrigerant : | R404A, R448A, R449A, R452A |
| Refrigerant Charge : | 7.26 kg |
